3M 180Cv3 Premium Cast Vinyl (Vinyl / Decals)

3M™ IJ180Cv3 Premium Cast Wrap Vinyl

When failure is not an option, this is the substrate you specify. Unlike standard calendared films that possess "shape memory" and shrink back over time, 3M™ IJ180Cv3 is a 2.0 mil premium cast vinyl engineered to stretch, conform, and stay down in deep channels, over heavy rivets, and around extreme compound curves.

Equipped with 3M Controltac™ technology, the surface layer contains microscopic glass spheres that prevent the adhesive from grabbing until firm squeegee pressure is applied—allowing installers to slide, align, and snap massive panels into place effortlessly. Once pressed, Comply™ v3 invisible air channels deliver a glass-smooth, paint-like finish with zero trapped bubbles.

Ideal B2B Applications:

• Full & Partial Fleet Wraps: Cargo vans, Sprinters, box trucks, and passenger vehicles.

• Complex Industrial Surfaces: Corrugated trailers, riveted aluminum, and marine hulls.

• Long-Term Architectural: High-end exterior building signage demanding maximum multi-year UV stability.

• (Pro-Tip: For standard flat panels like Coroplast or Dibond where extreme conformability is not required, specify our 3M IJ35C to keep your client's budget lean).

Technical Specifications:

• Film Type: 2.0 mil Premium White Cast Vinyl

• Adhesive: Grey-pigmented, repositionable Controltac™ with Comply™ v3 (Air-Release)

• Conformability: Flat, simple curves, severe compound curves, corrugations, and extreme rivets

• Expected Exterior Life: Up to 10 years (Unprinted) / 5–7 Years Printed (Vertical exposure dependent)

• Lamination Note:Must be paired with a matching Premium Cast Overlaminate (selectable in the pricing calculator). Never pair a Cast print vinyl with a Calendared laminate, as the laminate will shrink over time and cause edge-curling.

Pre-Press & File Setup:

• Bleed: Please build 0.25" bleed on standard signs; 0.5" bleed recommended for vehicle wrap panels requiring edge-tucking.

• Tiling / Panel Overlap: If submitting tiled vehicle wrap graphics, please build in a standard 0.5" overlap between seams.

• Contour Cutting: Supply a 100% Magenta vector spot-color stroke named CutContour set to overprint.
